Triangular Three-Dimensional Wound Core Oil-Immersed Transformer

Product Overview

The triangular three-dimensional wound core oil-immersed transformer is a new type of transformer featuring an advanced core structure design. This transformer utilizes a triangular three-dimensional wound core structure, which significantly reduces core loss and noise while improving electrical performance and mechanical strength. It is widely used in power transmission and distribution systems, offering high efficiency, energy savings, and low noise.

Key Features

1.Triangular Three-Dimensional Wound Core Structure: The unique triangular core design effectively reduces no-load loss and no-load current, improving overall transformer efficiency and significantly lowering operating costs.

2.Low Noise: The core is manufactured using a continuous winding process, which reduces core seams, thereby lowering operating noise. This makes it suitable for noise-sensitive environments.

3.Excellent Cooling Performance: The transformer uses oil as both an insulating and cooling medium, cooling through natural convection or forced oil circulation, ensuring stable operation under high load conditions.

4.High Mechanical Strength: The triangular core structure provides excellent mechanical stability, allowing the transformer to withstand significant mechanical stress during transport and operation, reducing the risk of damage.

5.Energy Saving and Environmentally Friendly: The transformer is designed and manufactured with a focus on energy efficiency and environmental protection, aligning with modern green development standards and reducing environmental impact.

Application Areas

Power Transmission and Distribution Systems: Widely used in urban and rural power grids, substations, and other power supply systems.

Industrial Applications: Suitable for industrial sites with high power demands, such as factories, mines, and metallurgical enterprises.

New Energy Sector: Used for power transmission and conversion in wind energy, solar energy, and other renewable energy generation systems.

Technical Parameters

· Rated Voltage: Customizable according to customer requirements, suitable for various voltage levels.

· Capacity Range: From tens of kilovolt-amperes (kVA) to several thousand kilovolt-amperes (kVA), meeting the needs of various applications.

· Cooling Methods: natural cooling (ONAN).

Conclusion

With its high efficiency, low noise, and environmentally friendly advantages, the triangular three-dimensional wound core oil-immersed transformer has become an essential device in modern power systems. Our company offers a variety of specifications for triangular wound core oil-immersed transformers to meet the needs of customers in different application scenarios, ensuring the safe, stable, and efficient operation of power systems.
