Product Overview
The European box-type substation is a power device that integrates high-voltage switchgear, distribution transformers, low-voltage distribution equipment, and other functions within a single enclosure. Its compact structure, flexible installation, and stable performance make it widely applicable in urban power grids, commercial areas, and industrial parks. The European box substation emphasizes aesthetic design while ensuring good protection and reliable operational characteristics, making it suitable for various outdoor and harsh environments.
Key Features
1. Modular Design: The European box-type substation adopts a modular design for high-voltage, transformer, and low-voltage components, facilitating installation, operation, and maintenance while reducing construction time.
2. Small Footprint: With a compact structure, it occupies minimal space, making it ideal for installation in areas with limited space, such as urban power grids, residential communities, and commercial districts.
3. High Safety: The enclosure is made of high-strength materials, providing excellent protection against external environmental impacts, ensuring the long-term safe operation of the equipment.
4. Good Heat Dissipation: Equipped with advanced ventilation and cooling systems, it maintains stable operation under high-load conditions, extending the equipment's service life.
5. Flexible Application Scenarios: Suitable for power supply needs in various environmental conditions, it possesses strong corrosion resistance, moisture-proof, and dust-proof capabilities, making it ideal for outdoor installation.
6. Eco-Friendly and Energy Efficient: Using high-efficiency energy-saving transformers, it meets national energy conservation standards, reduces energy consumption and carbon emissions, and supports the application of green and environmentally friendly power projects.
Application Areas
Urban Power Grids: Suitable for urban power supply systems, providing stable power transmission and distribution services.
Commercial and Residential Areas: Widely used in the power supply systems of residential communities, commercial centers, etc., ensuring safe and reliable power supply.
Industrial Parks: Suitable for the high-power energy needs of industrial sectors, such as factories, mines, and large industrial parks.
Technical Parameters
Rated Voltage: Customizable according to customer requirements, with common voltage levels of 10kV, 20kV, or 35kV.
Capacity Range: From several hundred kilovolt-amperes (kVA) to several thousand kilovolt-amperes (kVA), meeting power needs in different scenarios.
Cooling Methods: Typically uses natural air cooling or forced air cooling systems to ensure efficient heat dissipation under varying load conditions.
Conclusion
The European box-type substation, with its modular design, small footprint, flexible installation, and energy-efficient characteristics, has become a key piece of equipment in modern power systems. Our company offers a variety of specifications for European box-type substations that can be customized to meet specific customer requirements, ensuring the safe, stable, and efficient operation of power systems.
| Product Model | Rated Capacity（kVA） | HV（KV） | Tapping Range（%） | LV（KV） | Connection Group | No-load Loss（W) | load loss （W）(120℃) | Short-circuit Impedance（%） | Dimensions (Length ×Width × Height) （mm) | Gauge（mm） | Total Weight（KG) |
| S11-M-30/10 | 30 | 6 6.3 6.6 10 10.5 11 | ±5 ±2×2.5 | 0.4 | Yyn0 Dyn11 | 100 | 630/600 | 4 | 705*510*930 | 400*400 | 290 |
| S11-M-50/10 | 50 | 130 | 910/870 | 4 | 830*520*1020 | 400*400 | 400 | ||||
| S11-M-63/10 | 63 | 150 | 1090/1040 | 4 | 850*520*1024 | 400*400 | 395 | ||||
| S11-M-80/10 | 80 | 180 | 1310/1250 | 4 | 860*540*1040 | 400*400 | 465 | ||||
| S11-M-100/10 | 100 | 200 | 1580/1500 | 4 | 890*570*1030 | 400*400 | 510 | ||||
| S11-M-125/10 | 125 | 240 | 1890/1800 | 4 | 935*580*1130 | 400*400 | 630 | ||||
| S11-M-160/10 | 160 | 280 | 2310/2200 | 4 | 1175*725*995 | 550*550 | 690 | ||||
| S11-M-200/10 | 200 | 340 | 2730/2600 | 4 | 1120*765*1035 | 550*550 | 765 | ||||
| S11-M-250/10 | 250 | 400 | 3200/3050 | 4 | 1185*830*1095 | 550*550 | 930 | ||||
| S11-M-315/10 | 315 | 480 | 3830/3650 | 4 | 1255*880*1075 | 550*550 | 1085 | ||||
| S11-M-400/10 | 400 | 570 | 4520/4300 | 4 | 1400*1010*1170 | 550*550 | 1300 | ||||
| S11-M-500/10 | 500 | 680 | 5410/5150 | 4 | 1450*1045*1210 | 660*660 | 1450 | ||||
| S11-M-630/10 | 630 | 810 | 6200 | 4.5 | 1540*1080*1275 | 660*660 | 1680 | ||||
| S11-M-800/10 | 800 | 980 | 7500 | 4.5 | 1610*1150*1370 | 660*660 | 2010 | ||||
| S11-M-1000/10 | 1000 | 1150 | 10300 | 4.5 | 2070*1265*1850 | 660*660 | 2720 | ||||
| S11-M-1250/10 | 1250 | 1360 | 12000 | 4.5 | 2050*1265*1890 | 820*820 | 3150 | ||||
| S11-M-1600/10 | 1600 | 1640 | 14500 | 4.5 | 2155*1320*2010 | 820*820 | 3850 | ||||
| S11-M-2000/10 | 2000 | 1940 | 18300 | 5 | 1950*1950*1995 | 960*960 | 4570 | ||||
| S11-M-2500/10 | 2500 | 2290 | 21200 | 5 | 2060*2050*2610 | 1080*1080 | 4980 |
| Key attributes | |
| Phase | Three |
| Other attributes | |
| Place of Origin | Jiangsu, China |
| Brand Name | HuaDing |
| Model Number | S11 |
| Coil Number | 3 |
| Use | power |
| Coil Structure | layer coil |
| Certification | CE ISO |
| Standard | IEC60076 |
| Type | Distribution Transformer |
| Frequency | 50/60HZ |
| Input Voltage | 6-11kV |
| Output Voltage | 0.38-0.44kV |
| Tapping Range | ±5，±2×2.5 |
| Warranty | 2 Years |
| Winding material | Copper\Aluminum |
| Cooling Method | ONAN |
| Ambient Temperature | ‘-25℃ to 40℃ |
| Operating Altitude | Below 1000 meters |
| Delivery Time | |||
| Quantity (Pieces) | 1-5 | 6-10 | ＞10 |
| Delivery Time (Days) | 22 | 27 | To be determined |
| Product Specifications and Model | Standard | Quantity (Units) | Price (USD) | ||
| SL11-M-25/10/0.4 | Aluminum , IEC | 1 | 1060 | ||
| SL11-M-30/10/0.4 | Aluminum , IEC | 1 | 1130 | ||
| SL11-M-50/10/0.4 | Aluminum , IEC | 1 | 1310 | ||
| SL11-M-63/10/0.4 | Aluminum , IEC | 1 | 1530 | ||
| SL11-M-80/10/0.4 | Aluminum , IEC | 1 | 1650 | ||
| SL11-M-100/10/0.4 | Aluminum , IEC | 1 | 1800 | ||
| SL11-M-125/10/0.4 | Aluminum , IEC | 1 | 1990 | ||
| SL11-M-160/10/0.4 | Aluminum , IEC | 1 | 2230 | ||
| SL11-M-200/10/0.4 | Aluminum , IEC | 1 | 2490 | ||
| SL11-M-250/10/0.4 | Aluminum , IEC | 1 | 2830 | ||
| SL11-M-315/10/0.4 | Aluminum , IEC | 1 | 3200 | ||
| SL11-M-400/10/0.4 | Aluminum , IEC | 1 | 3570 | ||
| SL11-M-500/10/0.4 | Aluminum , IEC | 1 | 4420 | ||
| SL11-M-630/10/0.4 | Aluminum , IEC | 1 | 5210 | ||
| SL11-M-800/10/0.4 | Aluminum , IEC | 1 | 7140 | ||
| SL11-M-1000/10/0.4 | Aluminum , IEC | 1 | 9210 | ||
| SL11-M-1250/10/0.4 | Aluminum , IEC | 1 | 9770 | ||
| SL11-M-1600/10/0.4 | Aluminum , IEC | 1 | 11500 | ||
| SL11-M-2000/10/0.4 | Aluminum , IEC | 1 | 14490 | ||
| SL11-M-2500/10/0.4 | Aluminum , IEC | 1 | 16220 | ||
| PS：Ex-factory Price for Standard Product,Custom Products Available for Inquiry. | |||||
